TL2030 Strong Crusher | Standard Crushing Equipment For Small & Medium-sized Injection Workshops

The small & medium-sized injection molding production and micro plastic recycling processing industry is in urgent need of special crushing equipment with small footprint, low power consumption, easy maintenance and high cost performance. Tenlong TL2030 small strong crusher is a standard small crushing model of TL series, equipped with a 4KW national standard special drive motor. It is specially adapted to working conditions of small & medium-sized injection molding factories and micro plastic processing plants, dedicated to crushing injection molding sprue, defective small plastic parts and mixed soft & hard plastic leftovers. It is a mainstream entry-level plastic crusher for small-batch plastic recycling granulation. Featuring compact footprint and zero-basis easy operation, it fully meets standardized safe production, environmental noise reduction operation requirements of domestic small & micro factories.

1. Cutter Assembly Configuration, Wear-resistant Design Cuts Consumable Cost Greatly

TL2030 strong crusher is factory-equipped with imported SKD11 high-alloy formed cutter. The rotor adopts a combined structure of 15 rotary moving blades + 2 fixed stationary blades, forming a bidirectional cross shearing structure with uniform meshing cutting force. It can crush soft and hard plastics stably without material jamming or slipping.

The machine is standard equipped with flat blade rotor, supporting lossless replacement of adjustable claw blade rotor, realizing free switching of two working modes in one machine: Flat blade fits cutting soft plastic and thin leftover materials, with fine discharging and ultra-low dust; Claw blade is for powerful crushing of thick hard plastics and large injection molding sprue, greatly improving crushing efficiency.

All blades adopt telescopic adjustable installation structure. Passivated blades can be disassembled, polished and reused for many times without replacing the whole cutter body. It fundamentally reduces blade procurement cost and manual cost of disassembly and grinding, bringing better long-term operation economy.

1. Core Capacity & Body Structure Detailed Parameters

This strong crusher is equipped with a 4KW national standard pure copper motor, with constant spindle speed of 650rpm. It comes with a standard 6mm wear-resistant punching screen mesh with customizable aperture, standard hourly output of 125–275kg, perfectly matching small & medium-sized injection workshops and plastic processing plants with daily waste output of 1–5 tons.

Built-in crushing chamber size: 315×160mm, with sufficient feeding space. Palm-sized block plastic parts can be directly fed, ensuring smooth feeding and avoiding material bridging, blocking and stacking problems. The integrated thickened steel welded body features high rigidity, shock and impact resistance, not easy to deform or crack welds after long-term crushing hard plastics. Net weight: 395kg, overall dimension: 980×742×1260mm. Compact size allows placement at workshop corners or idle stations, occupying no effective production space.

Complete Technical Parameter Table of TL2030

III. Standard Configuration & Optional Upgrade Accessories

Full Standard Configuration List of Strong Crusher

Basic crushing host, standard flat blade cutter set, integrated steel sealed body, motor overload power-off protection, cover-opening safety interlock protection, basic sound insulation shock absorption structure, standard closed material receiving port.

Optional Upgrade Accessories

Feed port magnetic iron removal device: Adsorb metal screws and iron scraps in raw materials, preventing hard metal from entering crushing chamber to bend or damage cutter set, extending blade service life;

Dust separation recycling system: Filter fine crushing dust, optimize workshop working environment, recycle fine plastic powder synchronously to improve overall raw material utilization rate;

This machine is not equipped with water cooling, automatic conveying and full material alarm function for normal-temperature plastic crushing. For factories processing high-temperature and ultra-thick large hard plastic blocks, upgrade large-scale water-cooled TL50 / TL70 strong crusher for heavy-duty 24-hour continuous production.

1. Full-scenario Application Scope

Small & medium-sized injection molding processing factories: Recycling small home appliance plastic parts, daily plastic shells, plastic toy sprue and defective injection molding leftovers;

Small granulation workshops: Unified crushing of PP, PE, ABS, PC common soft and hard plastics, linked with small granulator units;

R&D laboratories and sampling workshops: Plastic raw material sample crushing and small-batch new product trial production crushing;

Micro recycling stations: Crushing and recycling scattered packaging plastic waste and small plastic scraps.

This strong crusher can be equipped with universal moving casters for flexible station shifting. Matched with a simple material receiving box, it can independently complete the whole crushing and material recycling process without building complex supporting production lines.
