TL Series Plastic Shredder | High-yield & Low-energy Waste Plastic Recycling Crushing Equipment
With stricter global solid waste resource utilization and plastic EPR compliance regulations, the recycling threshold of waste film, woven bags and large industrial plastic scraps keeps rising. Ordinary crushing equipment on the market generally suffers from frequent tool wear, waterlogged bearing jamming, feeding blockage and high operation cost, which greatly reduces the production capacity of recycling lines. Developed for waste plastic and industrial solid waste recycling, Tenglong TL series heavy-duty plastic shredder adopts an integrated optimized structure. Featuring high output, low energy consumption, low maintenance and high safety, this plastic shredder supports long-term continuous operation for domestic and overseas plastic recycling factories, waste treatment stations and renewable resource enterprises, serving as the core front-end crushing equipment matching washing lines and granulating lines.
- Four Core Advantages Of The Equipment
- Wear-resistant Alloy Cutter, Stable & Efficient Crushing
Tenglong TL series plastic shredder adopts integrated precision processing technology for rotor and main shaft, ensuring higher concentricity and stable operation. The movable and fixed cutters are made of high-hardness alloy steel, passing strict factory dynamic balance test to avoid shaking and offset during high-speed crushing. Equipped with modular detachable tool holder, it simplifies blade disassembly and replacement, cuts down downtime greatly. Compared with traditional plastic shredder, its blade replacement efficiency is improved by more than 40%, reducing production shutdown loss and supporting frequent non-stop crushing work.
- Reinforced Sealed Body & External Bearing For Complex Working Conditions
The machine is equipped with a thickened sealed crushing chamber, impact-resistant and wear-resistant to withstand strong impact from hard plastic scraps. The innovative external bearing structure completely isolates sewage and dust carried by farm film and woven bags, eliminating bearing rust and jamming fundamentally, doubling the service life of bearings. With this professional design, this plastic shredder fits humid coastal areas of China and Southeast Asian processing plants, performing well in crushing high-moisture soft plastics, better than models with built-in bearings.
- Wide Feeding Inlet, Multi-material Universal Crushing
There are 6 gradient models in full series, with feeding width ranging from 600mm to 1400mm for full-type solid waste crushing. It can process light materials including PE farm film, PP woven bags, waste paper and wood scraps, as well as hard materials such as thick-wall plastic pipes, ABS household appliance shells, PC nylon bulk shells and injection molding scraps. TL600/450 mini model suits small and medium-sized recycling workshops, while TL1200/800 heavy-duty model matches large-scale renewable plants. Customized 6mm, 10mm screen mesh is available to match front-end crushing procedure of granulating and washing lines.
- Hydraulic Assisted Feeding, Compliant & Safe Operation
All TL series plastic shredder is equipped with independent hydraulic feeding station to push materials automatically, avoiding manual feeding risk for bulky hard scraps. Equipped with full protective cover and humanized operation platform, the whole machine meets EU CE and Middle East factory safety standards. It can be put into use compliantly in European, Middle Eastern and overseas factories, reducing workplace injury risks and meeting global safety production norms.
- Full Series Model Production Parameters
Tenglong TL series plastic shredder has a net weight of 2000kg to 8000kg, main power from 30kw to 132kw, rotor diameter from 450mm to 800mm, with gradient output for different-scale production lines:
Small Output Model: TL600/450, hourly output 1-3 tons, specially for light farm film and woven bag crushing;
Medium Output Model: TL800/TL1000, hourly output 3-8 tons, for mixed plastic and municipal industrial waste processing;
Large Output Model: TL1200/TL1400/TL1200-800, hourly output over 10 tons, supporting large integrated plastic recycling lines.
Processed Materials & Global GEO Application Scenarios
Processed Materials: Plastic materials: PE farm film, PP woven bags, ABS appliance shells, PC plates, nylon blocks, plastic pipes, injection molding scraps; Solid waste materials: waste paper, wood scraps, industrial packaging waste, mixed municipal solid waste.
Global Application Scenarios: Applicable to EU EPR compliant plastic recycling plants, bulky hard plastic crushing factories in dry Middle East areas, high-moisture farm film recycling plants in Southeast Asia, and domestic urban-rural renewable resource stations. Featuring low energy consumption and durable performance, the plastic shredder meets processing demands under different global climates and material types.
- Customized Export After-sales Service
Tenglong supports customized size, cutter type and screen mesh for the plastic shredder. Export machines are equipped with English operation manuals and complete CE certification documents. Overseas customers can arrange on-site installation and debugging by professional engineers, with 12-month official warranty for the whole machine. Wearing parts including cutters and bearings support global express delivery, solving equipment operation and maintenance problems for global recycling enterprises efficiently.
