Tenglong Horizontal (Barrel-Type) Forced Feeding Plastic Pelletizer | High-Efficiency Recycling & Pelletizing Solution for Soft Plastic & Film Materials
As a key national city for the construction of the waste recycling system, Linyi boasts a mature waste recycling network and large-scale recycled plastics industry, forming two major industrial agglomeration hubs in Lanshan District and Hedong District alone. There are 27 PE recycled material-related enterprises concentrated in Lanshan District, covering the full industrial chain of recycling and pelletizing for PE film and soft plastics. Driven by robust market demand for agricultural film, packaging film, industrial film and other soft & film plastic scraps, local manufacturers are plagued by prevalent industrial bottlenecks: difficult feeding after crushing and troublesome moisture removal. Rooted in R&D and production of plastic recycling machinery in Linyi, Tenglong develops the Horizontal (Barrel-Type) Forced Feeding Plastic Pelletizer tailored to regional industrial demands and policy trends. This all-in-one machine resolves core production hurdles in soft plastic and film pelletizing, perfectly matching operational needs of PE film recyclers across Linyi, southern Shandong and East China, enabling compliant, eco-friendly and
high-yield production aligned with circular economy policies.
Plastic Pelletizer
1. Product Overview
The Horizontal (Barrel-Type) Forced Feeding Plastic Pelletizer is custom-engineered to tackle poor feeding of crushed PE film and soft plastics, serving as core production equipment to break output bottlenecks for local Linyi recyclers. Benefiting from Linyi’s efficient recycling model of “online reservation + offline collection”, plus industrial cluster advantages of Lunan Chemical Market (Lanshan), Bancheng Industrial Park, Bahu Industrial Park (Hedong), the machine features a patented horizontal barrel forced feeding structure: dry material adopts standard forced feeding while wet material uses forced feeding plus honeycomb perforated feeding barrel for in-barrel dewatering, compatible with both moist and dry raw materials for drastically boosted hourly output. Equipped with electromagnetic heating for wet-feed pelletizing, it thoroughly removes residual moisture and volatile contaminants to produce uniform pellets with minimal raw material loss and high finished product rate. Widely applicable to all categories of PE plastic recycling, it is ideal for local agricultural film and packaging film processing. It helps enterprises build a closed-loop circular economy chain of “Resources → Finished Products → Waste → Recycled Resources”, fulfilling core targets specified in Linyi Three-Year Action Plan for Industrial Transformation & Green Low-Carbon High-Quality Development (2023–2025): improving waste recycling system and raising recovery rate of agricultural plastic waste.
2. Core Technical Advantages
2.1 Patented Forced Feeding Structure Solves Blockage of Soft & Film Plastics
Local crushed PE soft scraps (agricultural film, packing film etc.) feature poor fluidity and frequent slipping leading to feeding blockage. Fitted with dedicated barrel-type forced feeding assembly, the pelletizer delivers stable continuous feeding; honeycomb drilled holes on feeding barrels drain excess water for wet feedstock to eliminate slip and no-feed issues, greatly lifting production efficiency for large-scale continuous manufacturing of recyclers in Lanshan and Hedong. It cuts manual operating costs especially for dirty, waterlogged film waste widely processed by local factories.
2.2 High-Efficiency Degassing & Impurity Removal for Superior Pellet Purity
Combining electromagnetic heating, optimized screw geometry and multi-stage exhaust ports, the equipment strips moisture and volatile impurities thoroughly to eliminate bubbling and smoking during wet plastic extrusion, yielding dense, glossy, dimensionally consistent pellets that fully satisfy downstream processing standards. As benchmark equipment among PE film pelletizers, it improves added value of recycled pellets for Linyi processors to access high-end downstream markets and sharpen product competitiveness, complying with national Specification Conditions for Comprehensive Utilization of Waste Plastics and Linyi’s policy of upgrading recycling quality and production efficiency.
2.3 Water Ring Hot Cutting with High Automation Level
After molten plastic is extruded, hot cutting via water-ring cutters is followed by cooling in circulating water ring and high-speed centrifugal dewatering, with full-process automatic operation. Dust-free working environment and low noise output produce smooth-cut uniform pellets with minimum manual input. The design effectively eases labor shortage and soaring labor cost troubles haunting Linyi recyclers, meets strict local environmental regulations for fully enclosed low-emission production, catering to concentrated plastic processing zones including Baishabu Town (Lanshan) and Zhengwang Town (Hedong) and facilitating smooth environmental compliance inspection for end users.
2.4 Dual-Purpose for Dry & Wet Raw Materials, Wide Working Condition Adaptability
One single unit handles two mainstream production modes: pelletizing of crushed dry film scraps and water-containing wet film feedstock, maximizing equipment utilization and lowering fixed asset investment for plastic recyclers. Matching Linyi’s differentiated raw material features (some factories process dry clean film, others dirty waterlogged film), this versatile universal dry/wet feed pelletizer fits all-sized PE soft & film recycling workshops ranging from individual family-run processors in Lanshan to large-scale plastic manufacturers in Hedong.
3. Main Technical Parameters (Tenglong TL Series)
Tenglong TL-series Horizontal (Barrel-Type) Forced Feeding Plastic Pelletizer boasts robust configuration with customizable specifications matching small, medium and large-sized PE plastic recyclers in Linyi and surrounding regions for flexible model selection per raw material property and production capacity:
| Model | TL-140 | TL-160 | TL-180 |
|---|---|---|---|
| Applicable Raw Material | Crushed dry/wet feed of all types PE film & soft plastic | Crushed dry/wet feed of all types PE film & soft plastic | Crushed dry/wet feed of all types PE film & soft plastic |
| Hourly Output (kg/h) | 250–300 | 300–400 | 400–500 |
| Main Extruder Screw Diameter & Rated Power | Φ140mm×3300mm / 75KW (6-pole motor) | Φ160mm×3300mm / 90KW (6-pole motor) | Φ180mm×3600mm / 110KW (6-pole motor) |
| Auxiliary Extruder Screw Diameter & Rated Power | Φ140mm×1780mm / 22KW (6-pole motor) | Φ160mm×1780mm / 30KW (6-pole motor) | Φ180mm×1780mm / 37KW (6-pole motor) |
| Pelletizing Mode | Vertical water ring hot cutting with variable frequency speed regulation | Vertical water ring hot cutting with variable frequency speed regulation | Vertical water ring hot cutting with variable frequency speed regulation |
| Dewatering Unit | High-speed vertical centrifugal dehydrator | High-speed vertical centrifugal dehydrator | High-speed vertical centrifugal dehydrator |
4. Machine Composition & Optional Auxiliary Equipment
User-friendly structural design of the soft plastic pelletizing machine enables ordinary workers to operate without professional technicians, aligning with Linyi recyclers’ demand for labor saving. The complete production line realizes full-automatic workflow from raw material feeding to finished pellet storage, conforming to standardized production criteria of recycled plastic industrial bases in Lanshan and Hedong:
- Main Extruder & Forced Feeding System: Assembled with horizontal barrel forced feeding device + two-stage screw extrusion system, realizing stable feeding, melting, degassing, filtering and extrusion to resolve inherent feeding difficulties of film & soft plastic scraps matching local raw material features;
- Water Ring Hot Cutting System: Consisting of water-ring cutting knife and circulating cooling ring to rapidly solidify extrudate and produce uniform-sized premium pellets for higher finished product rate;
- Dewatering Machine: High-speed vertical dehydrator removes surface moisture from cut pellets to avoid caking and damp deterioration, stabilizing finished pellet quality especially under wet-feed production;
- Storage & Screening Unit: Integrated 300kg/500kg storage hopper + vibrating screener for finished pellet storage and size classification, cutting raw material waste and satisfying varied specification requirements of downstream buyers;
- Optional Add-ons: Mixing tank and automatic feeder available for optional configuration based on customer output scale and feedstock characteristics to further boost production efficiency for customized manufacturing needs.
5. Applicable Scenarios & Target Customers
Leveraging Linyi’s national-level waste recycling policy dividends, industrial cluster effects of Lanshan & Hedong recycled plastic parks and massive local PE soft/film scrap volume, our dual-purpose dry/wet forced feeding plastic pelletizer serves diversified recycling projects across southern Shandong and East China with core client groups concentrated in and around Linyi:
- PE film & soft plastic recycling manufacturers focusing on agricultural film, packaging film and industrial film reprocessing, especially enterprises settled in Bancheng Industrial Park, Baishabu Town (Lanshan), Bahu Industrial Park (Hedong) requiring mass continuous production;
- Wet/dry mixed plastic film recycling projects plagued with chronic feeding blockage, simplifying production steps and lifting operational efficiency for local Linyi processors;
- High-output low-loss customized pelletizing production lines with hourly capacity from 250kg/h to 500kg/h, available for small individual workshops up to large-scale plastic manufacturing corporations;
- Eco-oriented PE plastic recyclers pursuing green circular development, helping operators qualify for government recycling subsidies and preferential taxation for comprehensive resource utilization under Linyi’s circular economy policies.
Plastic Pelletizer
6. Comprehensive Value of Tenglong Pelletizing Equipment
Against the backdrop of Linyi developing into a national demonstration city for waste circular economy and industrial upgrading of recycled plastic sectors in Lanshan and Hedong, our Horizontal (Barrel-Type) Forced Feeding Plastic Pelletizer fundamentally fixes three major pain points of PE film recycling: feeding obstruction, limited production capacity and troublesome moisture disposal. Thanks to innovative forced feeding and high-efficiency degassing technologies, production workflow is streamlined to slash labor and power consumption while improving pellet yield and quality, facilitating clients to pass environmental audits and achieve eco-friendly, compliant and profitable manufacturing.
As flagship PE soft film recycling pelletizer manufactured locally in Linyi, the equipment perfectly fits regional industrial layout and regulatory requirements, empowering recyclers in Lanshan and Hedong to optimize resource allocation and strengthen core competitiveness. It accelerates local recycled plastic industry’s transformation from scattered small workshops to standardized large-scale operation, lifts municipal agricultural film recovery rate, fuels rural vitalization and circular economy development, standing as ideal core equipment for complete PE film recycling pelletizing production lines.
