Automobile Dismantling Industrial Park Upgrades TL100120 Four-shaft Shredder, 60% Capacity Increase for Large Body Shredding

Medium and large end-of-life vehicle renewable industrial parks have long been restricted by four major industry pain points of traditional dual-shaft shredders: frequent material winding and cutter jamming, incapability of shredding thick materials, easy cutter chipping and frequent motor burnout, leading to limited production capacity and high operation and maintenance costs. A large-scale automobile dismantling industrial park in Shandong eliminated the old dual-shaft shredding production line, adopting dual-line collaborative operation of TL100120 flagship four-shaft shredder and TL9080 heavy-duty four-shaft shredder. Whole vehicles can be directly shredded without pre-cutting, achieving all-round upgrades in production capacity, sorting purity, safety and compliance, greatly shortening the payback period. The renovation solution can be replicated for automobile and household appliance dismantling parks nationwide.

1. Project Background

A formal large-scale automobile dismantling renewable industrial park in Shandong holds qualified end-of-life vehicle dismantling qualifications, with an annual compliant dismantling capacity of 3,000 passenger cars and freight vehicles, supporting complete downstream magnetic separation, air separation and non-ferrous metal sorting equipment. Before renovation, the park was equipped with two old 30kW dual-shaft shredders for primary shredding of vehicle chassis girders, interior plastics, wiring harnesses and metal frames, with concentrated production, maintenance and compliance pain points restricting long-term capacity expansion:

1. Frequent shutdowns due to material winding and jamming: Automotive plastic carpets, wiring harnesses and sound insulation cotton are extremely prone to winding dual-shaft cutter rollers, requiring manual disassembly and blockage removal 3–4 times per shift, with the effective equipment operation rate less than 60% and unmet production capacity;
2. Limited thick material shredding with high costs: Traditional dual-shaft machines lack sufficient torque to shred high-hardness automobile chassis girders and thick steel plate bodies directly, requiring pre-flame cutting and blocking, resulting in additional gas consumption and cutting labor costs with high pre-process expenses;
3. Heavy cutter loss and tedious maintenance: Original thin carbon steel cutters have poor impact resistance and are prone to chipping and wear when shredding metals, requiring shutdown surfacing repair every 4 days. Excessive monthly maintenance shutdown hours disrupt the park’s dismantling schedule;
4. Incomplete electric control protection with high failure rate: No intelligent overload reverse electric control function leads to direct motor burnout when hard materials jam the machine. Three main shaft motors were burnt out within one year, causing shutdown maintenance losses and order revenue reduction;
5. Poor discharge quality with low premium: Dual-shaft shredding produces many long strip materials and uneven particle sizes, increasing downstream sorting difficulty and high metal-plastic mixing rate, making recycled materials only sellable at low bulk prices.

In 2026, the park completed special upgrade of main line equipment, eliminating two old dual-shaft shredders, purchasing one TL100120 flagship four-shaft shredder for main line whole vehicle shredding and one TL9080 heavy-duty four-shaft shredder for shunting small household appliance waste, building a divided fully automatic shredding and sorting production line.

2. Customized Divided Shredding Production Line Solution
3. Main whole vehicle shredding host: Adopt TL100120 four-shaft shredderwith 44kW total dual-motor power (22+22kW), 1000×1200mm super-large feeding cavity and 40mm ultra-thick impact-resistant alloy steel cutter body. Complete end-of-life vehicles can be directly fed for shredding via crane hoisting without pre-flame cutting, adapting to heavy-duty whole vehicle crushing conditions;
4. Auxiliary small material shunting equipment: Equipped with TL9080 medium and large four-shaft shredderto specially shunt and process waste household appliance shells (refrigerators, washing machines, air conditioners) and scattered hardware waste, balancing the material flow of the entire production line and avoiding main line material accumulation and congestion;
5. Central control system docking: Both devices are equipped with unified Siemens PLC intelligent control cabinets with standardized reserved signal interfaces, seamlessly docking with the park’s full factory central centralized control system for one-click start-stop and remote monitoring of equipment current and operating hours;
6. Seamless production line renovation: The discharge height of both equipment matches the original belt conveyor, and shredded mixed materials are hermetically conveyed to magnetic separation and air separation sections to automatically separate ferrous metals, non-ferrous metals and plastic impurities, realizing unattended sorting and recycling.
7. Measured Multi-dimensional Efficiency Improvement and Cost Reduction Data
8. 60% increase in whole vehicle shredding capacity, easily meeting annual dismantling targets: The four-shaft differential staggered shearing design fundamentally eliminates wiring harness and film winding blockage, enabling 24-hour uninterrupted continuous operation without frequent shutdowns for blockage removal. The park’s daily whole vehicle shredding volume increased from 12 to 19 units, a 60% day-to-day capacity increase, easily completing the annual 3,000-unit dismantling target with extra capacity for external waste dismantling orders.
9. Elimination of pre-flame cutting process, 68% reduction in gas and labor costs: The 44kW peak high torque matched with 40mm thickened cutters can directly bite and shred high-hardness chassis girders and thick body steel plates, completely eliminating the pre-flame cutting process. 2 certified cutting workers are reduced per shift, saving propane gas consumption and cutting equipment maintenance costs, resulting in a 68% drop in comprehensive monthly production costs of labor and gas with zero pre-process labor costs.
10. 7 times longer cutter maintenance cycle, 75% reduction in consumable costs: The original thickened alloy cutters of thefour-shaft shredderhave excellent metal impact resistance, greatly slowing down steel shredding wear. A single surfacing repair supports over 30 days of stable continuous operation, compared with the 4-day repair cycle of old dual-shaft machines. Comprehensive costs of cutter repair, replacement and disassembly labor are reduced by 75%, monthly maintenance shutdown hours are cut by 85%, and production line continuity is greatly improved.
11. Near-zero equipment failures, dual compliance of factory safety and environmental protection: Full coverage of PLC intelligent automatic reverse anti-jam function automatically dredges hard material jams, completely avoiding motor burnout risks from overload. Zero motor burnout and gear cracking failures have occurred since commissioning. Three major protections (door opening interlock, overload power-off, external emergency stop) help pass the annual safety standardization audit of solid waste disposal by emergency management bureaus. Matched with original dust and noise reduction equipment, workshop dust and noise fully meet environmental inspection standards with no rectification or shutdown risks.
12. Regular discharge with high sorting purity, 200 RMB per ton premium for recycled materials: The four-shaft uniform four-sided shredding produces regular and uniform particle sizes without ultra-long strip impurities, greatly improving downstream magnetic and air separation efficiency, significantly enhancing metal purity and plastic cleanliness. High-purity sorted materials enjoy a stable market premium of 200 RMB per ton compared with mixed bulk materials, greatly expanding the park’s profit margin of waste deep processing.
13. Minimal equipment maintenance, improved park management and cost reduction: The four-shaft shredderadopts an integrated low-failure planetary transmission structure with durable anti-interference Siemens electric control. Daily maintenance only requires regular gear oil filling and feeding port impurity cleaning. The built-in fault self-inspection code enables zero-basic maintenance personnel to troubleshoot simple faults, eliminating the need for high-salary professional electromechanical maintenance personnel and further reducing park operation labor costs.



14. On-site Feedback from Park Equipment Supervisor

Park Equipment Supervisor Comment: With years of experience in automobile dismantling, material winding and incapability of shredding thick materials have always been industry bottlenecks. Upgrading to TL four-shaft shredder completely solves these two core pain points. The four-shaft differential anti-winding effect is remarkable, whole vehicles can be directly fed without pre-cutting, and the Siemens electric control ensures stable operation with few failures. The complete model gradient covers 15kW small auto repair models to 44kW top-tier whole vehicle models, suitable for small workshops and large industrial parks. It features heavy durability and fast investment return, ideal for long-term high-intensity dismantling mass production.

5. Replicable Standard Selection Guide for Peers

This divided shredding renovation solution is applicable to: end-of-life vehicle dismantling bases, large household appliance renewable industrial parks, medical hazardous waste disposal centers, electronic waste recycling plants, large hollow plastic barrel crushing bases. Standard selection guide: Within 5 tons daily output – TL80 series; 5–15 tons daily output – TL90 series; over 15 tons daily whole vehicle bulk dismantling – priority for TL100120 top-tier four-shaft shredder.
