Practical Cost Reduction & Efficiency Improvement Advantages of High-End 125 Type Granulator Preferred by Small Recycling Plants

  In the plastic recycling industry, small-batch mass production, material sample testing and scrap recycling are currently the lowest-threshold and most stable demand tracks for entrepreneurship and processing. However, many novice entrepreneurs easily fall into pitfalls: choosing low-cost and low-end small granulators will soon face problems such as screw wear, uneven plasticization, frequent screen blockage, disordered pelletizing and high energy consumption, resulting in low productivity, low-value defective particles and excessively high later maintenance costs that far exceed the equipment price difference. With mature and stable industrial-grade configuration, the high-end 125 type granulator has become the mainstream preferred equipment for small recycling plants, laboratory sample testing and scrap recycling, perfectly adapting to the production needs of small batch, high quality and low maintenance.

The biggest shortcomings of ordinary small granulators lie in poor core accessory materials, simple heating system and weak transmission structure. Ordinary carbon steel screws are not wear-resistant and easily strained and worn when processing impurity-containing recycled materials, requiring replacement and maintenance within a few months. The single heating coil causes uneven temperature control, leading to local scorching and insufficient plasticization, resulting in particles with many black spots and high defective rates. The manual screen changing structure requires frequent shutdown and disassembly, seriously interrupting the production rhythm. The upgraded high-end 125 type granulator targets and solves these common industry problems from the core structure, comprehensively improving equipment stability and finished product quality.

In terms of the core extrusion system, the 125 type granulator adopts a 125×2800mm ultra-long nitrided screw and a 159×2800mm nitrided barrel with overall nitriding reinforcement treatment. It features high surface hardness, high temperature resistance, wear resistance and carbon deposition resistance. Compared with ordinary carbon steel screws, its service life is several times longer. It can operate stably for a long time when processing waste mixed materials and thin-film crushed materials, greatly reducing annual accessory replacement and maintenance costs. Matched with a 225 type hard-tooth low-noise reducer, it delivers sufficient transmission torque, stable and silent operation without slipping or jittering, ensuring continuous and stable extrusion pressure and more uniform material plasticization.

The heating system is the key to determining granulation quality. This 125 type granulator adopts a dual-mode temperature control system of 60KW electromagnetic heating and independent heating coil. Different from the traditional single heating method, electromagnetic heating features fast heating speed, high thermal conversion rate and lower energy consumption, while the auxiliary heating coil achieves precise temperature compensation and stabilization with small overall temperature fluctuation. The temperature range can be flexibly adjusted according to different plastic materials, completely solving the problems of plastic scorching, poor plasticization and excessive particle defects, producing uniform and high-quality finished particles.

In terms of production continuity, the equipment is equipped with a 360 type electric screen changing head. The 310mm large-diameter screen provides sufficient filtering area to efficiently intercept sediment, impurities and aged materials and improve particle purity. The 2.2KW-6 adjustable speed motor drives the screen changing structure to realize fast screen replacement without equipment shutdown, greatly improving production continuity and avoiding productivity loss caused by frequent shutdowns. The rear end is matched with a 4000×350×260mm extended stainless steel cooling water tank to ensure full cooling and shaping of plastic strips, preventing adhesion and deformation and providing guarantee for accurate pelletizing.

In the finished product processing link, an 180 type alloy rotary cutter variable frequency pelletizer is adopted. The 3KW variable frequency motor realizes stepless speed regulation, and the hard and wear-resistant alloy cutter delivers flat cuts without burrs, producing uniformly sized particles with few broken materials. Matched with a 201 stainless steel storage bin and a 2.2KW dust removal fan, it realizes automatic air drying and dust removal, ensuring dry and clean finished particles that resist moisture deterioration during storage and effectively improve product market premium. The whole machine is equipped with a national standard variable frequency distribution box with multiple protections of overload, short circuit and phase loss, ensuring safe and stable equipment operation with an extremely low failure rate.

For small recycling plants, start-up entrepreneurs and material R&D enterprises, choosing the 125 type granulator can achieve stable mass production, high-quality output and low operation and maintenance costs with lower investment, balancing productivity, quality, energy consumption and stability. It features a short payback period and strong market adaptability, making it a high-cost-performance equipment for small-scale plastic recycling processing.

FAQ

Q1: What is the hourly productivity of the 125 type granulator? Is it suitable for mass production?

A: According to the dry/wet state and impurity content of raw materials, the stable hourly output of conventional clean PP/PE materials can reach 200–250kg, which is suitable for small-scale stable mass production, sample production and batch scrap recycling, fully meeting the daily productivity needs of small and medium-sized processing plants.

Q2: Is daily maintenance of the equipment complicated? Is the maintenance cost high?

A: The nitrided screw and barrel are wear-resistant and durable without easy damage, and the electric screen changing structure avoids frequent disassembly. Daily maintenance only includes regular screen cleaning, lubrication inspection and water tank cleaning, featuring simple maintenance, few consumables and extremely low annual operation and maintenance costs.

Call To Action

Feel free to contact us for free professional consultation to obtain detailed productivity data, power consumption details and customized process solutions of the 125 type granulator!

WhatsApp/WeChat: +86 15092868822 ｜ Email: [email protected]
